ADEPT® 175 SYSTEM PROPERTIES
ADEPT® wall cassettes are fast to assemble and individually demountable, allowing zero waste alterations, easy disassembly, and re-use. A 2400 mm cassette weighs around 69kg facilitating easy delivery in difficult access sites. The option to reconfigure buildings over time reduces operational costs and carbon, as well as allowing end of life disassembly and re-use of the entire building.
The ADEPT® wall system is comprised of structural insulated cassettes, so that additional primary structure is not necessary for buildings of 3 stories or less. Standard sizes are 175mm thick, 600mm wide, and various heights from 600mm up to 2400mm, in increments of 300mm (with story heights met with variable dimension junction elements). An additional external layer of rigid wood fibre insulation offers a variety of wall build-ups for a range of thermal insulation requirements.
Component Performance
| Characteristic (system only) | Declared Value |
|---|---|
| Resistance to fire | REI30 - REI90* |
| Thermal resistance R | 3.6 - 11.1 m2K/W** |
| Heat transfer coefficient U | 0.28 - 0.09 W/m2K** |
| Water impermeability | Provided by membrane |
| Durability | Class 2 |
| Formaldehyde emission class | E1 |
| Acoustic performance Rw | 58dB*** |
| Carbon A1-A3 | Declared Value |
| GWP Total | -73.728 kgCO2e |
| GWP Fossil | 108.432 kgCO2e |
| Biogenic | -182.16 kgCO2e |
* Subject to internal and external finish
** Subject to the thickness of the rigid wood fibre external insulation
*** With 100mm external rigid wood fibre insulation
Thermal Performance
| Plasterboard mm |
Rigid Wood Fibre mm |
ADEPT 175 mm |
Rigid Wood Fibre mm |
Air Gap mm |
Cladding mm |
Total* mm |
U-value W/m2K |
|---|---|---|---|---|---|---|---|
| 12.5 | 20 | 175 | 20 | 50 | 25 | 327.5 | 0.21 |
| 12.5 | 20 | 175 | 40 | 50 | 25 | 347.5 | 0.19 |
| 12.5 | 20 | 175 | 60 | 50 | 25 | 367.5 | 0.17 |
| 12.5 | 20 | 175 | 80 | 50 | 25 | 387.5 | 0.16 |
| 12.5 | 20 | 175 | 100 | 50 | 25 | 407.5 | 0.14 |
| 12.5 | 20 | 175 | 140 | 50 | 25 | 447.5 | 0.12 |
| 12.5 | 20 | 175 | 180 | 50 | 25 | 487.5 | 0.11 |
-
Structural insulated timber panel with layers of HempSil® and IndiNature IndiTherm® flexible hemp insulation. An additional external layer of rigid wood fiber insulation offers a variety of wall build-ups for a range of thermal insulation requirements.
-
The system comes in various standard sizes with bespoke components available. See all modules here.
-
Residential, Student Housing, Commercial, Hotels, Healthcare, Education, Retail, Garden Studios, Cabins
-
